Specifications and parameters
Hardware
- Fixed port
- 1*2.5G + 3*10/100/1000Base-T Ethernet ports
Independent reset key, function keys (Mesh, wireless optimization)
- Wireless
- 2 omnidirectional antennas & 3-set of directional antennas
- CPU
- IPQ5018+IPQ5000
- Indicate light
- Front LED: system status indicator
Rear LED: 1 WAN port status indicator
- Dimensions (W×D×H)
- 220*220*300mm
- Power consumption
- ≦ 48W
- Cooling method
- Natural cooling
- Product standards
- YD/T 1096-2009
- Certification
- China Compulsory Certification
SRRC certification
China RoHS, EU RoHS
Network access license by Ministry of Industry and Information Technology of the PRC
Wireless
- Wireless protocol
- 2.4GHz：802.11ax/n/g/b
5GHz：802.11ax/ac/n/a
- Operating frequency band
- 802.11ax/ac/n/a : 5.15-5.35GHz，5.725GHz-5.850GHz(China)
802.11ax/n/b/g: 2.4GHz-2.483GHz(China)
- Spatial flow
- 2*2.4GHz 2x2 MIMO
3*5GHz 4x4 MIMO
- Wireless bandwidth
- 2.4G 20/40MHz
5G 20/40/80/160MHz
- Wireless rate
- Multi-frequency concurrency 14,986Mbps
2.4GHz：574Mbps & 5GHz：14,412Mbps
- Wireless roaming
- Support IEEE 802.11k/v
- MU-MIMO
- Upstream and downstream MU-MIMO
Software
- Internet connection
- Routing mode: DHCP/PPPoE/Static IP
Bridge mode: wired relay/wireless relay
- EasyMesh
- Available
- IPv6
- Available
- Security features
- WPA3 encryption
Anti-Wi-Fi squatting/anti-attack
Firewall, DMZ attacks
- Network management
- Guest Wi-Fi, access allowlist/denylist, parental controls based on multiple periods, IP-based traffic control, Wi-Fi timing switch
- Features
- UU Game Booster, Qos traffic shaping, broadband password retrieval, packet fast-forwarding engine, virtual server
- Management method
- Support for H3C Magic APP (iOS, Android), Web (moshujia.cn or http://192.168.124.1)
- Fault diagnosis
- Link detection
Internet diagnosis
Smart cloud maintenance
Professional customer service via WeChat
One-click uploading of fault information
Convenient goods-exchanging
Operating environment
- Operating temperature
- 0°C–40°C
- Storage humidity
- 10%–90%, RH non-condensing
Package
- Packing list
- Integrated machine
Quick Start Guide
Networking cable: Cat 5e cable
Warranty card
Certificate of Conformity
